SUBO
Rooting sound in pure gravity
SUBO deepens the foundation and physical energy of any combination of
STAVI series
| Tranducers | 15 inches TetraCoil woofer |
| Frequency range (-6dB) IEC 60238 | 20Hz to 120Hz |
| Nominal directivity (-6dB) | |
| SPL max @1m (CTA2034 11,9dB crest factor signal) | xxxdB measured IEC 61672 class 1 |
| dBSPL peak@1m (CTA2034 11,9dB crest factor signal) | xxxdB measured IEC 61672 class 1 |
| Maximum input level | +18 dBu, balanced |
| SPL out/4dBu input @1m (CTA2034 11,9dB crest factor signal) | xxdBLZpeak/84dBC slow |
| THD @+4dBu input level | -60dB |
| Processing | 96kHz 40bit floating point DSP |
| Connectors | PowerconTRUE1/xlrAES IO/xlr analog IO |
| Dimensions (H x W x D) | 758x532x454mm with front grill and back cache |
| Finish | Varnished |
| Cabinet | Pollmeier BauBuche Multiligne |
| Weight | |
| Rigging | Optional |
